Multi-Mode Tampilan
numeric Keypad
programmable Mode
DTMF Encode / Decode
PTT ID Tampilan
Primer / Group ID
Auto Dial DTMF Memori
Suara Scambler / compander
mendiamkan
scan
Sibuk Channel Lockout
baterai Simpan
frekuensi Reverse
VOX / sensitif / Delay
Time Out Timer
Call / Monitoring
Baterai Rendah Alert
bandwidth dipilih
Daya H / L dipilih
frekuensi Offset
frekuensi Langkah
Radio FM
Senter LED
Nonaktifkan Remote / Stun
programmable Keys
1750KHz Amatir Sinyal
(1) Dasar
Channel Kapasitas: 128
QT / DQT: 51 QT / 107 DQT
Rentang Frekuensi: UHF: 400-470MHz / 435-480MHz 330-400MHz
VHF: 136-174MHz
Dimensi H × W × T (Kecualikan Antena): 100 × 55 × 30mm
Berat (Termasuk baterai, antena, beltclip): 203g
Power Supply: DC 7.4V
Rapid Pengisian: Ya (Operasi temp: -20 ~ +55
Tipe Baterai: Li-ion 1100mAh (Li-ion Baterai)
Battery Life (5/5/90 duty cycle): ≥ 8 jam
(2) Receiver
Sensitivitas (12 dB SINAD):-119dBm (0.25μV)
Berdekatan Ch Selektivitas: 65dB @ 25KHz / intermodulation
55dB@12.5KHz:> 60dB
Hum dan Noise: ≥ 40dB @ 25KHz
Emisi tersebar: ≤ 7,5 μW
Blocking: ≥ 85dB
Audio Distortion: ≤ 10
Audio Output Power: 430mW @ 8Ω
(3) Transmitter RF Power
Output: H: 4W / L:
Stabilitas Frekuensi 1W: ± 2,5 PPM
FM Kebisingan dan bersenandung: ≥ 40dB @ 25KHz
Modulation Terbatas: ± 2,5 @ 12.5KHz; ± 5.0 Ch @ 25KHz
Dampingan Power: ≥ 65dB
Karakter Modulation:
dB ± 3 tersebar dan Harmonisa: ≤ 7.5μW
Audio Distortion: 10%
